Product Introduction
A Truss Gantry Crane is a type of gantry crane designed with a truss structure main girder instead of a traditional box girder. The truss structure is usually made of welded steel plates, angle steel, channel steel, round tubes, or square tubes. Due to its open web design, the truss gantry crane has the advantages of lighter self-weight, lower wind resistance, convenient transportation, and stable lifting performance, especially for outdoor lifting applications.
Compared with box girder gantry cranes, truss type gantry cranes are often selected for outdoor yards, construction sites, precast concrete yards, hydropower projects, road and bridge construction, steel structure fabrication yards, and material storage areas where wind load, transportation convenience, and cost efficiency are important considerations.
ZOKECRANE truss gantry cranes are designed and manufactured by Henan Zoke Crane Co., Ltd., a professional lifting equipment manufacturer specializing in overhead cranes and gantry cranes. Our manufacturing base is located in Changyuan, Henan Province, one of China’s major crane production centers. With extensive experience in crane engineering, design, manufacturing, and quality control, ZOKECRANE provides practical and customized truss gantry crane solutions for international customers.
The truss gantry crane is generally composed of a truss main girder, support legs, lower end beams, crane traveling mechanisms, trolley or electric hoist, lifting mechanism, electrical control system, power supply system, and safety protection devices. According to different lifting requirements, it can be designed as a single girder truss gantry crane, double girder truss gantry crane, rail mounted truss gantry crane, semi gantry crane, or portable truss gantry crane.
This type of crane is suitable for lifting and transferring steel bars, steel structures, precast concrete components, pipes, formwork, molds, construction materials, machinery parts, and other medium or heavy materials. ZOKECRANE can customize the crane according to lifting capacity, span, lifting height, cantilever length, rail length, working duty, outdoor environment, wind load requirements, power supply, control method, transportation size, and destination country requirements.
Main Features of ZOKECRANE Truss Gantry Crane
- Truss structure main girder with open web design
- Lighter self-weight compared with some box girder structures
- Lower wind resistance, suitable for outdoor applications
- Stable lifting performance and reliable traveling operation
- Suitable for large span and outdoor yard lifting
- Convenient for sectional manufacturing and export transportation
- Single girder and double girder designs available
- Rail mounted and semi gantry structures available
- Electric hoist or trolley lifting mechanism available
- Customized lifting capacity, span, lifting height, and cantilever
- Suitable for construction sites, precast yards, and storage yards
- Variable frequency control available for smoother operation
- Multiple safety devices for lifting and traveling protection
- Designed according to customer site conditions and working requirements
- Export-oriented packaging and logistics support available
Main Components
A truss gantry crane usually consists of the following main components:
| Component | Description | Function |
|---|---|---|
| Truss Main Girder | Open web steel structure made of angle steel, channel steel, steel tubes, or welded components. | Supports the trolley or hoist and bears the lifting load. |
| Support Legs | Steel structure legs connected with the main girder and lower end beams. | Transfer the load from the main girder to the ground traveling mechanism. |
| Lower End Beams | End carriage structures equipped with wheels and traveling drive units. | Allow the whole crane to travel along rails or ground track. |
| Lifting Mechanism | Electric wire rope hoist, hoist trolley, or winch trolley. | Lifts and lowers materials safely. |
| Trolley or Hoist Traveling Mechanism | Mechanism that moves the hoist or trolley along the main girder. | Transfers the load across the span of the crane. |
| Crane Traveling Mechanism | Motor, reducer, brake, wheel sets, and drive units. | Drives the entire gantry crane along the working route. |
| Electrical Control System | Electrical cabinet, cables, control buttons, remote control, and protection devices. | Controls lifting, trolley traveling, crane traveling, and safety functions. |
| Safety Devices | Limit switches, overload protection, emergency stop, buffers, rail clamps, and windproof devices. | Improve crane operation safety, especially for outdoor working conditions. |
Common Types of Truss Gantry Crane
ZOKECRANE can provide different truss gantry crane types according to lifting capacity, span, working duty, installation site, and application requirements.
| Type | Description | Typical Application |
|---|---|---|
| Single Girder Truss Gantry Crane | A gantry crane with one truss main girder and an electric hoist. | Construction sites, storage yards, small and medium lifting tasks |
| Double Girder Truss Gantry Crane | A gantry crane with two truss main girders and a trolley lifting mechanism. | Heavy-duty lifting, precast yards, steel structure yards |
| Rail Mounted Truss Gantry Crane | Travels on ground rails and is suitable for fixed working routes. | Outdoor yards, precast plants, material handling lines |
| Truss Semi Gantry Crane | One side travels on an elevated runway and the other side travels on ground rails. | Factories with limited space or existing building structures |
| Portable Truss Gantry Crane | Light-duty movable gantry crane with truss structure. | Maintenance, workshops, temporary lifting operations |
| Outdoor Truss Gantry Crane | Designed for outdoor operation with windproof and weather-resistant configurations. | Construction sites, open storage yards, bridge construction projects |
Typical Technical Parameters
The following parameters are for general reference. ZOKECRANE can customize truss gantry cranes according to project requirements and site conditions.
| Item | Specification |
|---|---|
| Product Name | Truss Gantry Crane |
| Alternative Name | Truss Type Gantry Crane / Truss Girder Gantry Crane |
| Crane Structure | Single girder / double girder / semi gantry / portable type |
| Main Girder Type | Truss structure main girder |
| Lifting Capacity | 3 ton, 5 ton, 10 ton, 16 ton, 20 ton, 32 ton, 50 ton or customized |
| Span | Customized according to site layout |
| Lifting Height | Customized according to lifting requirements |
| Cantilever | No cantilever / one-side cantilever / two-side cantilever |
| Working Duty | Customized according to application |
| Lifting Mechanism | Electric wire rope hoist / hoist trolley / winch trolley |
| Control Method | Pendant control / wireless remote control / cabin control |
| Speed Control | Single speed / dual speed / variable frequency control |
| Power Supply | Cable reel / sliding wire / diesel generator option / customized |
| Crane Traveling | Rail mounted traveling / ground traveling according to design |
| Working Environment | Indoor / outdoor |
| Application | Construction site, precast yard, steel yard, bridge project, storage yard |
| Safety Devices | Overload limiter, limit switch, emergency stop, buffer, rail clamp, windproof device |
| Certification | ISO, CE, SGS available |
Applications of Truss Gantry Crane
The truss gantry crane is widely used in outdoor and semi-outdoor lifting operations. Because of its truss structure, lighter self-weight, and lower wind resistance, it is particularly suitable for large outdoor working areas and long-term material handling projects.
Construction Sites
At construction sites, truss gantry cranes are used to lift and transfer construction materials, steel bars, formwork, prefabricated parts, machinery components, tools, and structural materials. The crane can improve lifting efficiency and reduce manual handling risks.
Precast Concrete Yards
In precast concrete yards, truss gantry cranes are used for handling precast beams, concrete slabs, wall panels, molds, columns, and other prefabricated components. The crane can be customized with suitable span, lifting height, working duty, and outdoor protection devices.
Road and Bridge Construction
Truss gantry cranes can be used in road and bridge construction projects for lifting bridge beams, steel structures, formwork, construction modules, and reinforcement materials. For special bridge construction applications, the crane structure can be customized according to project requirements.
Steel Structure Fabrication Yards
In steel structure fabrication yards, truss gantry cranes are used for lifting steel plates, steel sections, welded beams, truss components, pipes, steel frames, and fabricated modules. The crane can be equipped with hooks, lifting beams, clamps, or magnets according to the materials being handled.
Outdoor Storage Yards
Truss gantry cranes are suitable for loading, unloading, stacking, and transferring materials in outdoor storage yards. Their relatively low wind resistance makes them practical for open-air environments.
Hydropower and Infrastructure Projects
For hydropower stations, dam construction, and infrastructure projects, truss gantry cranes can support the lifting of construction materials, machinery parts, steel structures, gates, pipes, and maintenance components.
Machinery Manufacturing and Assembly Areas
Truss gantry cranes can also be used in machinery manufacturing plants and assembly areas for lifting equipment parts, frames, molds, and large components.
Temporary or Project-Based Lifting Operations
Because the truss structure can be manufactured in sections and transported more conveniently, truss gantry cranes are often used for temporary construction projects, remote sites, and project-based lifting operations.
Why Choose ZOKECRANE Truss Gantry Crane?
Professional Gantry Crane Manufacturer
ZOKECRANE is operated by Henan Zoke Crane Co., Ltd., a professional lifting equipment manufacturer specializing in overhead cranes and gantry cranes. Our manufacturing base is located in Changyuan, Henan Province, one of China’s major crane production centers.
Customized Truss Structure Design
ZOKECRANE can design truss gantry cranes according to lifting capacity, span, lifting height, working duty, wind load, outdoor environment, installation site, transportation limits, and customer application requirements.
Suitable for Outdoor Applications
The open truss structure helps reduce wind resistance, making the crane suitable for outdoor yards, construction sites, precast concrete yards, and infrastructure projects. ZOKECRANE can also provide rail clamps, anchoring devices, anemometers, warning lights, outdoor electrical protection, and anti-corrosion painting.
Efficient and Practical Lifting Solution
ZOKECRANE focuses on providing efficient and practical lifting solutions for different industrial applications. The truss gantry crane is a cost-effective choice for many outdoor material handling projects requiring stable lifting performance and convenient transportation.
Reliable Hoist and Trolley Options
Based on the requirements of overseas customers, ZOKECRANE has developed optimized trolley mechanisms and reliable wire rope electric hoists. Truss gantry cranes can be equipped with electric hoists, hoist trolleys, or winch trolleys according to project requirements.
Strict Quality Control
ZOKECRANE has established a comprehensive quality management system and obtained ISO, CE, and SGS certifications. We control the quality of raw materials, steel structure fabrication, welding, machining, assembly, electrical systems, painting, testing, packaging, and delivery.
International Export Experience
ZOKECRANE products have been supplied to customers in Russia, Uzbekistan, the Philippines, Bangladesh, Australia, Qatar, Tanzania, Singapore, Saudi Arabia, Brazil, Nigeria, and many other countries and regions. We understand overseas project communication, export packaging, shipping documentation, and international logistics requirements.
Technical Support and After-Sales Service
ZOKECRANE can provide crane selection support, general arrangement drawings, foundation and rail layout drawings, electrical diagrams, installation manuals, operation manuals, spare parts lists, and remote technical support for international customers.
Frequently Asked Questions About Truss Gantry Crane
1. What is a truss gantry crane?
A truss gantry crane is a gantry crane with a truss structure main girder. Compared with a box girder design, the truss structure has an open web form, which can reduce wind resistance and may reduce self-weight in suitable designs. It is commonly used for outdoor lifting operations.
2. What is the difference between a truss gantry crane and a box girder gantry crane?
The main difference is the structure of the main girder.
A truss gantry crane uses an open truss structure made of steel plates, angles, channels, or tubes. It has lower wind resistance and is often suitable for outdoor use.
A box girder gantry crane uses a closed box-type girder. It usually has higher torsional rigidity and is widely used for heavy-duty industrial applications.
The suitable design depends on lifting capacity, span, working duty, wind load, site conditions, and budget.
3. Is “Truss Gantry Crane” or “Truss Type Gantry Crane” more commonly used?
Both names are understandable and commonly used. However, Truss Gantry Crane is shorter and more suitable for product titles, SEO keywords, and product categories. Truss Type Gantry Crane is useful in product descriptions and technical explanations.
4. What lifting capacity can ZOKECRANE provide?
Common lifting capacities include 3 ton, 5 ton, 10 ton, 16 ton, 20 ton, 32 ton, and 50 ton. Larger or special capacities can be customized according to working requirements, structure type, span, lifting height, and application.
5. Can the truss gantry crane be used outdoors?
Yes. Truss gantry cranes are very suitable for outdoor applications. For outdoor use, ZOKECRANE can provide windproof devices, rail clamps, anchoring systems, rain covers, outdoor electrical protection, anti-corrosion painting, anemometers, warning lights, and alarms.
6. Can the crane be designed with cantilevers?
Yes. ZOKECRANE can design the truss gantry crane with no cantilever, one-side cantilever, or two-side cantilevers. Cantilevers can extend the lifting area beyond the crane span and improve loading and unloading convenience.
7. What lifting mechanisms are available?
Depending on the lifting capacity and application, the truss gantry crane can be equipped with:
- Electric wire rope hoist
- Hoist trolley
- Winch trolley
- Customized lifting mechanism
For medium-duty applications, an electric wire rope hoist is often selected. For larger capacity or higher duty applications, a trolley or winch system may be more suitable.
8. What control methods are available?
Common control methods include:
- Pendant control
- Wireless remote control
- Cabin control
- Combined control methods
Wireless remote control is commonly used for outdoor applications because it allows operators to control the crane from a safer and more flexible position.
9. What safety devices can be provided?
ZOKECRANE can provide safety devices such as:
- Overload limiter
- Lifting limit switch
- Trolley traveling limit switch
- Crane traveling limit switch
- Emergency stop
- Buffer
- Rail clamp
- Windproof anchoring device
- Anti-collision device
- Anemometer
- Warning light and alarm
- Phase sequence protection
- Voltage loss protection
- Motor overload protection
- Safety hook latch
10. What information is needed for quotation?
To provide an accurate quotation for a truss gantry crane, please provide:
- Lifting capacity
- Crane span
- Lifting height
- Cantilever length, if required
- Rail length or traveling distance
- Indoor or outdoor working environment
- Local wind condition or wind speed requirement, if available
- Material to be lifted
- Daily working hours or working duty
- Required lifting speed and traveling speed
- Lifting mechanism preference
- Control method preference
- Power supply voltage and frequency
- Destination country or port
- Site layout drawing, if available
- Special requirements such as lifting beams, magnets, grabs, or anti-sway control
11. Can ZOKECRANE design the crane according to transportation size limits?
Yes. For export projects, ZOKECRANE can consider container size, road transportation limits, site access conditions, and installation convenience during the design stage. The truss structure can often be manufactured in sections to help reduce transportation difficulty.
Export and Logistics FAQ for ZOKECRANE Truss Gantry Crane
1. Can ZOKECRANE export truss gantry cranes overseas?
Yes. ZOKECRANE has experience in supplying crane equipment to international customers. Our products have been exported to Russia, Uzbekistan, the Philippines, Bangladesh, Australia, Qatar, Tanzania, Singapore, Saudi Arabia, Brazil, Nigeria, and many other countries and regions.
2. How is the truss gantry crane packed for export?
For export shipment, the truss gantry crane is usually divided into transportable sections. Truss girder sections, support legs, lower end beams, hoist or trolley mechanisms, traveling mechanisms, electrical cabinets, motors, reducers, brakes, cables, bolts, and accessories are packed according to sea transportation and long-distance delivery requirements.
Steel structures are usually marked, bundled, fixed, and protected. Electrical components, small parts, spare parts, and control systems are usually packed in wooden cases or export-standard packages.
3. Can a truss gantry crane be shipped by container?
Yes. Many truss gantry cranes can be shipped by standard container if the girder and structural parts are designed in suitable sections. For large spans, long sections, or heavy components, open-top containers, flat rack containers, or bulk cargo shipment may be required.
During design and packaging planning, ZOKECRANE can consider transportation dimensions and container loading requirements to help customers choose a practical shipping method.
4. What shipping methods are available?
Common shipping methods include:
- Standard container shipping
- Open-top container shipping
- Flat rack container shipping
- Bulk cargo shipping
- Land transportation
- Railway transportation
- Multimodal transportation
The suitable shipping method depends on the crane dimensions, total weight, component length, destination country, transportation route, delivery time, and project budget.
5. Can ZOKECRANE assist with international shipping?
Yes. ZOKECRANE can assist with shipment arrangement according to the agreed trade terms. Customers can also appoint their own freight forwarder if preferred.
6. What export documents can ZOKECRANE provide?
ZOKECRANE can usually provide the following export and technical documents:
- Commercial invoice
- Packing list
- Bill of lading
- Certificate of origin, if required
- Product certificate
- Quality inspection report, if required
- CE documents, if required
- SGS-related documents, if required
- Operation manual
- Installation manual
- General arrangement drawing
- Foundation and rail layout drawing
- Electrical drawing
- Packing drawing
- Spare parts list
- Test report, if required
The actual document list can be prepared according to customer requirements, trade terms, customs clearance needs, and destination country regulations.
7. Can ZOKECRANE provide installation guidance for overseas customers?
Yes. ZOKECRANE can provide installation drawings, foundation and rail layout drawings, electrical diagrams, operation manuals, installation manuals, and remote technical guidance. For specific overseas projects, installation service can be discussed according to project requirements.
8. What should be checked before installation?
Before installing a truss gantry crane, customers should check:
- Foundation condition
- Rail gauge, straightness, elevation, and fixing condition
- Site access and installation space
- Power supply voltage and frequency
- Installation tools and auxiliary lifting equipment
- Truss girder sections
- Support legs
- Lower end beams
- Hoist or trolley mechanism
- Crane traveling mechanisms
- Electrical cabinets and cables
- Bolts, fasteners, pins, and accessories
- Windproof devices and safety components
- Technical drawings and installation instructions
9. What should customers check after receiving the crane?
After receiving the truss gantry crane, customers should check:
- Package condition
- Quantity of components
- Shipping marks and packing list
- Truss girder sections
- Support legs
- Lower end beams
- Hoist or trolley mechanism
- Lifting mechanism
- Crane traveling mechanisms
- Motors, reducers, brakes, and wheels
- Electrical cabinets and control components
- Cables and accessories
- Bolts, fasteners, pins, and connecting plates
- Rails and rail accessories, if included
- Nameplates and markings
- Safety devices and windproof components
- Technical documents and drawings
- Spare parts, if included
If any damage, shortage, or package problem is found, please contact ZOKECRANE promptly with photos, packing list, and shipping documents.
10. How long does production and delivery take?
Production and delivery time depends on lifting capacity, span, lifting height, cantilever length, rail length, structure type, working duty, electrical system, customization level, order quantity, production schedule, and shipping route.
After confirming technical requirements, drawings, commercial terms, and payment arrangement, ZOKECRANE can provide a production and delivery plan.
11. Can the truss gantry crane design help reduce shipping cost?
Yes. The truss structure can often be divided into sections for transportation. ZOKECRANE can optimize the structural design, section length, package dimensions, and container loading plan to help reduce shipping costs while ensuring structural strength and convenient installation.
