FEM Standard Double Girder Gantry Crane

1. Technical Parameters
2. FEM standard double girder gantry crane with FEM 3m/4m/5m heavy-duty working class, European box girder structure, full VFD control, high fatigue resistance. Custom large span & heavy tonnage for precast yard, steel plant and port outdoor heavy lifting.
3. Lifting Capacity: 10Ton – 500Ton (Main/Aux hook optional)
• FEM Working Class: FEM 3m / 4m / 5m
• Working Duty: A5 – A8
• Span: 10m – 80m (Customizable)
• Lifting Height: 6m – 50m (Customizable)
• Hoisting Speed: Variable VFD speed
• Trolley Travel Speed: VFD adjustable
• Gantry Travel Speed: VFD adjustable
• Control Mode: Pendant / Wireless Remote / Cabin / Dual control
• Power Supply: 380V/400V/415V 50/60Hz Custom
• Protection Grade: IP54 / IP65
• Working Temperature: -20°C ~ +50°C

Product Overview

FEM standard double girder gantry crane is a heavy-duty outdoor lifting solution designed strictly in accordance with European FEM & DIN industrial standards. Different from conventional domestic gantry cranes, it adopts optimized double box girder structure, high anti-fatigue steel structure and full variable frequency control system. Supporting large tonnage, long-span and 24-hour frequent continuous operation. It is the preferred equipment for high-standard industrial yards, precast concrete factories, steel stockyards, port terminals and large engineering projects worldwide.

Core Advantages

•Heavy-Duty FEM Grade Design: Standard FEM 3m/4m/5m fatigue level, suitable for long-term high-intensity cyclic work.
•Double Box Girder European Structure: High rigidity, strong stability, no deformation under long-span heavy load.
•Main & Aux Dual Hook Optional: Realizes heavy-load main lifting and precise auxiliary lifting, improving working efficiency.
•Low Wheel Pressure Optimization: European lightweight design reduces foundation load, saving construction investment.
•Full VFD Infinitely Variable Speed: Anti-sway, smooth start-stop, accurate positioning and low noise.
•Complete EU Safety System: Multi-level intelligent protection, fully compliant with CE machinery directive.
•Long Service Life: FEM fatigue calculation ensures structural safety for more than 15 years of frequent operation.

FEM Working Class Instruction

FEM 3m：Standard heavy duty, most widely used for precast yard and steel factory daily operation.
FEM 4m：High-frequency heavy duty, for all-day continuous industrial lifting.
FEM 5m：Super heavy cycle, 24/7 non-stop working for port and large industrial base.
Support customized FEM duty calculation report for tender and project acceptance.

Core Components & European Configuration

Double European Box Main Girder：High-strength steel welding, integral anti-fatigue structure.
Heavy-Duty Machined End Carriage：Precision processing, low wear, stable long-distance traveling.
European Open Winch Trolley：Professional for double girder heavy-load high-cycle work.
Global Brand Electrical Parts：Siemens / ABB / Schneider optional.
Full VFD Control System：Smooth operation, energy-saving and anti-sway effect.
Bolted Modular Structure：Less field welding, fast installation and high safety.

Full Safety & Intelligent System

•FEM standard overload limiting system
•Double upper & lower lifting limit protection
•Trolley & gantry travel limit + buffer device
•VFD intelligent anti-sway system
•Wind speed detector & automatic rail clamp
•Emergency stop & anti-collision system
•Rainproof, dustproof and salt-fog anti-corrosion system
•Optional remote IoT monitoring & fault diagnosis

Customization Options

•Main + Aux dual hook system
•Explosion-proof FEM standard configuration
•Coastal heavy anti-corrosion paint system
•Full intelligent anti-sway & precise positioning
•Air-conditioned operator cabin
•Low-temperature resistant design for cold regions
•Long cantilever & super large span customization

Application Scenarios

Large precast concrete yard, heavy steel stockyard, port and terminal logistics, wind power and hydropower projects, mining industry, heavy machinery workshop, large infrastructure construction, European standard industrial projects and government bidding works.

FEM Professional Export Service

•Free FEM fatigue & working cycle calculation report
•EU standard technical drawings and construction solution
•Complete CE certification and technical files
•Heavy-duty sea-worthy anti-rust packaging
•Overseas engineer installation guidance
•Long-term original FEM-grade spare parts supply

FAQ

Q1: What is FEM standard double girder gantry crane?
It is a European heavy-duty gantry crane designed according to FEM/DIN fatigue standards. The double box girder structure supports larger load, longer span and higher working cycle than conventional gantry cranes, specially built for high-standard industrial projects.
Q2: What is the difference between FEM single girder and double girder gantry crane?
FEM double girder type supports heavier tonnage, longer span, higher FEM 4m/5m super-duty grade and dual hook configuration, suitable for continuous heavy-load industrial work.
Q3: Can you provide FEM calculation report for bidding?
Yes, we provide official FEM working cycle calculation documents, structural fatigue analysis and full technical files for project tender and approval.
Q4: Does FEM double girder gantry crane support custom span and tonnage?
Fully customizable. We design exclusive solutions according to your site span, lifting height, load capacity and working frequency.
Get your tailor-made FEM standard double girder gantry crane solution and official FEM calculation report! Please inform your lifting capacity, span, lifting height, working frequency and site conditions. We will provide professional EU-standard technical proposal and competitive quotation within 24 hours.
